HR4138S Industrial RFID Reader Controller for TIRIS Proximity Tag
Product Number：HR4138SHR4138S RFID Proximity Tag CIDRW Controller
Designed for industrial automation, asset management, and semiconductor applications.
Supports DC 10–24V power input, typical frequency 134.2 kHz (FSK), compatible with TIRIS single-page and multi-page tags.
Equipped with RS-232C or RS-485 interface, built-in SEMI SECS protocol, fixed 9600 bps transmission rate, supports long-distance communication up to 1000 m.
Compact and durable (128 × 91 × 31 mm), weight 320 g.
Power supply: DC 10~24V, low power consumption (60mA average, 160mA peak)
• Frequency: 134.2KHZ FSK, supports TIRIS single-page and multi-page labels
• Environment: Operating temperature -10 - +70°C, humidity resistance up to 85% RH, suitable for industrial environments
• Communication: RS-232C / RS-485, 9600bps (fixed), SEMI SECS protocol, transmission distance up to 1000 meters
• Construction: Weight 320g, Dimensions 128x91x31 mm, Sturdy mounting design (M4 screws)
• Applications: Industrial automation, semiconductor manufacturing, asset tracking, access control
General Specifications
| Characteristic | Specification | Comment |
| Supply Voltage Range | DC 10 ~ 24V | Supplied from the power terminals |
| Current consumption @12VDC | Average 60mA ; Peak 160mA | Approx. 2A max, with rush current |
| Transmitting Radio Frequency | Typical 134.2KHz | FSK |
| Transponder Type | TIRIS Tag | Single & Multi page Transponder |
| Operating ambient temperature | -10 ~ +70°C | No freezing |
| Operating ambient humidity | 10 ~ 85% RH | No dew condensation |
| Storage ambient temperature | -20 ~ +85°C | No freezing |
| Storage ambient humidity | 5 ~ 95% RH | No dew condensation |
| Communication interface | RS-232C or RS-485 | 9600 bps (Default), N.8.1 (fixed) |
| Weight | 320g MAX. | No freezing |
| Dimensions | 128 × 91 × 31 mm | Except for protrusions on connectors |
| Mounting system | Secured with two M4 screws | Use the enclosed washers |
Communication Interface Specification
| Characteristic | Specifications |
| Connector specification | RJ45 connector plug |
| Communication standard | RS-232C or RS-485 (only for use with HR4135S GateWay Controller) |
| Synchronization | Asynchronous mode, start-stop synchronization |
| Communications control standard | SEMI SECS protocol |
| Total cable length | RS-232C: 15 m Max. RS-485: From HR4135S to last HR4136S, 1000 m Max. |
