ACS6

• Controls every critical access point; personnel may pass only according to configured permissions
• The full system can accommodate 100,000 users and store 1,000,000 records
• The system features password protection and permission levels, allowing administrators to manage hierarchy and subsystem access rights
• Hardware devices adopt a hierarchical modular design; the main controller’s data transmission is fully based on TCP/IP Ethernet
• Multiple access control modes allow different control methods for different areas, which can be used in combination
• The software is protected by KeyPro security device; without it, access to the software is not possible

Main System Functions

• Configuration of personnel role classification and permission assignment
• Configuration of access time permissions for personnel
• Configuration of personnel accounts, departments, job titles, and access groups
• Personnel basic information management with photos for inquiry and verification
• Personnel basic information can be added individually or imported from a file
• Configuration of accessible elevator floors, shared with the access control database to avoid duplicate setup
• Provides configuration of user permissions for adding, deleting, modifying, and exporting data in programs to simplify management
• Supports data permission control, allowing assignment of multiple administrator accounts with appropriate permissions
• Access card and system log inquiry, printing, downloading, and exporting
• Alarm message system log inquiry, printing, downloading, and data exporting
• System event log inquiry: searchable by event time, category, content, etc.
• Provides scheduling services to enhance system automation management
• System supports manual or automatic time synchronization to keep all readers’ date and time consistent
• Supports reader group duplication (including reader parameters, time zone tables, and holiday tables)
• Provides configuration of different access time tables, holiday tables, parameter tables, and free-access time tables for different readers
• Reader names can be customized by administrators for easier identification
• Supports downloading of access cards
• Configurable card start and end validity time
• Perpetual calendar forms allow configuration of holiday access schedules for the entire year, supporting cross-year holiday tables (depending on product model)

System Environment

• 可運行於 Windows 7、 Windows 8 、Windows 10/11以上等專業版作業系統

Supported Product Models

• Supports all model series

Hardware Requirements

• CPU: Intel Core i5 or equivalent eight-core processor or above
• Memory: 16GB DDR4 or above
• Storage: 100 GB SSD (system disk) + backup storage space
• Built-in network port: Gigabit Ethernet (1Gbps)
• USB port: x 1 for hardware protection key
