e-AMS

• Controls every critical access point; personnel may pass only according to configured access permissions
• Hardware devices adopt a hierarchical modular design
• Multiple access control modes that can be used in combination
• Software supports USB hardware protection key (KeyPro)
• Automatically detects reader connection status and restores connection after disconnection

Main System Functions

• Configuration of personnel role classification and permission assignment.
• Configuration of access time permissions for personnel.
• Configuration of personnel accounts, departments, job titles, and access groups.
• Personnel basic information management with photo files for inquiry and verification.
• Configuration of accessible elevator floors, shared with the access control database to avoid duplicate setup.
• Provides group- or role-based management to configure user permissions for adding, deleting, modifying, and exporting data, simplifying administration.
• Provides group-based management to configure permitted access time schedules for each door controller, with unlimited group quantity.
• Supports data permission control and allows assignment of multiple administrator accounts with appropriate permissions.
• Access card and system log inquiry, printing, and downloading; data can be exported to Excel or CSV files.
• Alarm message system log inquiry, printing, and downloading; data can be exported to Excel or CSV files.
• System event log inquiry: searchable by event time, category, content, operator, and source IP.
• Allows querying the current connection status of readers and communication converters via the web interface.
• Allows querying reader firmware version and model information via the web interface.
• Provides scheduling services to enhance system automation management.
• The system provides automatic time synchronization.
• Perpetual calendar forms allow configuration of holiday access schedules for an entire year, supporting cross-year holiday tables.
• Supports reader group duplication (including reader parameters, time zone tables, and holiday tables).
• Provides configuration of different access time tables, holiday tables, parameter tables, and free-access time tables for different readers.
• Supports downloading of access cards and patrol cards.
• Supports basic LDAP authorization, Modbus TCP, and one-time QR Code.

System Environment

• Server supports Windows Server 2016 / 2019 / 2022 (or Windows 10/11 Professional and above)
• Client supports Windows 7 / 10 and above
• Browsers: Google Chrome, Microsoft Edge (latest version recommended)
• Database: Microsoft SQL Server 2016 / 2019 / 2022 (including Express free edition)
• Web platform: Microsoft IIS 10.0 or later

Hardware Requirements

• CPU: Intel Core i5 or equivalent eight-core processor or above
• Memory: 16GB DDR4 or above
• Storage: 100 GB SSD (system disk) + backup storage space
• Built-in network port: Gigabit Ethernet (1Gbps)
• USB port: x 1 for hardware protection key
