- Wide Card Compatibility: Fully supports ISO/IEC 14443A cards, including Mifare Classic, Ultralight, and DESFire.
- Multiple Model Options: Available in standard Mifare card reader or fingerprint card reader versions, allowing flexible selection based on on-site security requirements.
- Robust Physical Protection: Equipped with a dedicated tamper output wire and housed in an ABS enclosure with the highest UL94V0 flame-retardant rating, ensuring safety and durability.
- Intuitive Status Indication: Built-in multi-color LED indicators and buzzer provide clear, real-time feedback on reader status.
- Stable Communication Performance: Supports standard Wiegand interface for seamless integration with access controllers from major brands.
- Excellent Reading Range: Card reading distance up to 5 cm, with anti-interference circuit design to ensure accurate and reliable detection.
General Specifications
| Characteristic | Specification | Description |
| Operating Voltage | DC +10 ~ 15V | Linear voltage regulator recommended |
| Current Consumption | 100mA max. @DC12V | |
| Card Format | ISO/IEC 14443A | Reading distance up to 5 cm |
| Tamper Output | Open Collector, active low | Maximum output current: 100 mA |
| Transmission Distance | Up to 150 meters (500 feet) using 18AWG shielded cable | |
| Indicator LEDs | LED (Blue, Green, Red) | LED colors indicate different system statuses |
| Operating Temperature | 0 ~ 55°C | |
| Operating Humidity | 5 ~ 95% | |
| Dimensions (L x W x H) | 120 x 72 x 24 mm | |
| Weight | 150 g max. | |
| Housing Material | ABS (UL94V0) | |
| External Control | Supported | LED indicators and buzzer can be controlled externally |
